Electronic Flasher Relay

Sale!
Electronic Flasher Relay

Electronic Flasher Relay

Original price was: $12.00.Current price is: $7.83.

35 in stock

SKU: 3071 Category:

Description

Electronic Flasher Relay | Honda CB175 / CB200 / CB350 / CB360 / CB450 / CB500 / CB550 / CB750

If your turn signals stay on solid, flash erratically, or you are converting to LED bulbs — this electronic flasher relay is the fix. Unlike the OEM thermal flasher that depends on high current draw from incandescent bulbs, this solid-state relay works with both incandescent and LED turn signals. No load resistors needed.

Why You Need This

The original Honda thermal flasher relay uses a bimetallic strip heated by current flow to create the on-off flash pattern. It depends on the higher current draw of incandescent bulbs to generate enough heat to cycle. When you swap to LED turn signals — which draw far less current — the thermal flasher will not trigger. Your signals stay on solid or do not light at all.

This electronic relay uses a solid-state circuit with a low current threshold, so it flashes reliably with LED bulbs, incandescent bulbs, or a mix of both. It is a direct plug-in replacement for the OEM thermal relay — same two-terminal design, same wiring connector. If your original relay has simply failed from age, this electronic version is the upgrade path whether you are running LEDs or not.

Specifications

Spec Detail
Replaces OEM Parts 38301-KJ6-743, 38300-292-670, 38301-KJ6-741, 38301-KJ6-742
Fits Models CB175 / CL175 / SL175 (1968–1973), CB200 / CL200 (1973–1976), CB350 / CL350 / SL350 (1968–1973), CB360 / CL360 / CJ360 (1974–1977), CB450 / CL450 (1965–1974), CB500T (1975–1976), CB500K (1971–1973), CB550K / CB550F (1974–1978), CB750 (1969–1978)
Voltage 12V
Type Solid-state electronic (low current threshold)
Terminals Two spade: + (battery/12V positive) and – (load)
Compatibility Works with incandescent bulbs, LED bulbs, or mixed
Sold As Single unit

Note: This relay is polarity-sensitive. If the turn signals turn on but do not flash, the wiring is reversed — swap the two connections. The black wire (12V+) goes to the + terminal, the gray wire goes to the – terminal.

Installation

Difficulty: Beginner

  1. Locate the flasher relay — on most models it is mounted under the seat near the battery or inside the headlight bucket.
  2. Pull the two-wire connector off the old relay and remove it from the mounting bracket.
  3. Connect the new relay: black wire (12V+) to the + terminal, gray wire to the – terminal.
  4. Turn the key on and test both turn signals.

Troubleshooting: If the signals turn on but do not flash, the relay is connected backwards — reverse the two wires. Also check your connectors for corrosion and inspect the left-hand control switch to make sure it is making good contact.
